Adjustable Rail Clips

The HoldFast Range of Adjustable Rail Clips

Adjustable Rail Clip Benefits
•	A wide degree of lateral adjustments allows precise alignment of rails
•	Alleviates problems caused by misalignment of studs
•	Design permits high bolt torques and prevents side slip
•	High quality casting in SG iron
•	Suitable for overhead gantry and ground track installations

Manufactured and Stock Items
•	Base Plates
•	Resilient Reinforced Pads
•	Holding Down Bolts
•	Bolts
•	Weldable Studs
•	Vertical Levelling Devices
•	Epoxy Resin Grouts
•	Other Track Materials

Shell Produced Castings in S.G.Iron (Ductile Iron) to BS 5750 part 2 and ISO 9002

Renowned Worldwide

Since 1987 HoldFast have been manufacturing their range of adjustable rail clips in the UK. These uniquely patented products are now sold in 16 country's worldwide. The Range encompasses the 'Soft'; 'Hard' and 'Spring' Clip.

Winning Features

HoldFast clips are manufactured from ductile iron with the advantage of better castability than steel, giving a smooth clean profile and more strength for less expense. Galvanising and cadmium plating are available if required. Other coatings (e.g. plastic) are also available for customer requirements.

The Highest Standard

HoldFast clips are produced by the well established 'Shell Moulded Process' which enables all castings to be very accurately produced and consistent to the drawings, to comply with B.S.2789 and DIN 1693.

The Clips are designed so that they can be 'tailor made' for any rail section.

The clips accommodate Rail Expansion due to climate conditions; Even though the rail is held in positive lateral alignment.

Clips are fitted in pairs, opposite each other, with calculations determining both diameter and longitudinal centres of fixing bolts.
